HPY200 — Safety Yellow Single LED Industrial Signal

Description

HPY200 — Safety Yellow Single LED Signal

HP Series High-Power Single LED Traffic Signal

HPY200 Series high-flux single LED traffic signal with 8" (200mm) diameter safety yellow polycarbonate housing. High-output LED signal with cap-style visors and universal L-shaped mounting brackets. Available in AC or DC.

Features Include:

• IP65 rated modular housing
• 200mm (8") diameter LED module
• Safety yellow polycarbonate housing
• Removable cut-away style visors
• L-brackets included for vertical or horizontal mounting
• Low power all-LED construction for long life and low operating cost
• Screw terminal strip for easy wiring to your control switching
• AC: 100–277VAC, 50/60Hz, 6W maximum per module
• DC: 12–24V, 6W maximum per module
• 3/8 mile (>500M) viewing distance
• 3-year limited warranty on LED modules

Available Colors:

• 🔴 Red
• 🟡 Yellow
• 🟢 Green
• 🔵 Blue (+$20.00)
• ⚪ White (+$20.00)

Note: If ordered with a flasher installed, the AC flasher operates at 120VAC and the DC flasher operates at 10–24VDC.

Compatible AC Flasher:

AFAC1 — AC Single Channel LED Flasher

Compatible DC Flasher:

AFDC1 — DC Single Channel Flasher

Want It Pre-Installed?

Add Factory Installation Service — $20.00 — We’ll install your flasher into your signal head before it ships.

Download HP200 Series Spec Sheet (PDF)

Also available in: Gloss Black Single LED — HPB200

Spec sheet covers all HP200 Series modules. Product on the shelf subject to prior sale.

Call us for pricing and availability: 316.409.4911
